{"id":7872531461,"title":"APlusLift HW-10KBP-A 10,000 LB 2-Post Floor Plate Heavy Duty Car Lift 24 Months Parts Warranty (FREE SHIPPING)","handle":"apluslift-2-post-car-lift-hw-10kbp","description":"\u003cul\u003e\n\u003cli\u003e\n\u003ch3\u003eCombo (Symmetrical and Asymmetrical) Arm Assembly with Screw-in Pads!\u003c\/h3\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003ch3\u003eCE Certified Lift Structure and Hydraulic System\u003c\/h3\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003ch3\u003e6'9\" Lift Height Maximum with Truck Adapters\u003c\/h3\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003ch3\u003eAll Robot Welded Structure with Durable Powder Coated Finish\u003c\/h3\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003ch3\u003eDouble Seal Rings Protecting PU Material\u003c\/h3\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003ch3\u003eCarriage Material Q355 (ASTM A572), Stronger Than Normal Q235 Steel\u003c\/h3\u003e\n\u003c\/li\u003e\n\u003c\/ul\u003e\n\u003ch3\u003eAPlusLift HW-10KBP-A car lift (auto hoist) is one of the most affordable floor plate car lift with 10,000 LB Heavy Duty and Strong Double \"S\" Column Design. Our auto lifts are upgraded to use thicker steel for stronger support (Column Steel upgraded to 13\/64\" from 11\/64\"; Carriage and Arm Steel upgraded to 15\/64\" from 3\/16\"; Carriage yoke upgraded to 9\/16\" from 15\/64\")\u003c\/h3\u003e\n\u003ch3\u003eAPlusLift HW-10KBP-A car lifts are built with quality materials and good workmanship. We do not use recycled materials to save cost for parts such as cylinder seal rings. Suggestions to improve our products and service are always welcome!\u003c\/h3\u003e\n\u003ch3\u003eSelf Pickup Locations with Discount: Los Angeles (CA), Atlanta (GA), Indianapolis (IN), Kansas City (MO), Charlotte (NC), New Holland (PA), Dallas (TX), and Tacoma (WA).\u003c\/h3\u003e\n\u003ch3\u003eFrequently Asked \u003ca href=\"\/pages\/product-order-and-shipping-questions\"\u003eProduct, Order, and Shipping Questions\u003c\/a\u003e and \u003ca href=\"\/pages\/installation-questions#10k\"\u003eInstallation Questions\u003c\/a\u003e\n\u003c\/h3\u003e\n\u003ch3\u003e\u003cspan style=\"color: red;\" color=\"red\"\u003ePlease Note We Are The Only Seller of APlusLift Products on The Website, Amazon, and eBay.\u003c\/span\u003e\u003c\/h3\u003e\n\u003ch2\u003eSpecification and Features\u003c\/h2\u003e\n\u003cul\u003e\n\u003cli\u003e\u003ca href=\"https:\/\/cdn.shopify.com\/s\/files\/1\/1751\/1741\/files\/APlusLift_HW-10KBP.pdf?v=1610167906\"\u003eInstallation Manual\u003c\/a\u003e\u003c\/li\u003e\n\u003c\/ul\u003e\n\u003cul\u003e\n\u003cli\u003eColumn Steel Thickness: 13\/64\"\u003c\/li\u003e\n\u003cli\u003eCarriage Steel Thickness: 15\/64\"\u003c\/li\u003e\n\u003cli\u003eCarriage Yoke Thickness: 9\/16\"\u003c\/li\u003e\n\u003cli\u003eArm Steel Thickness: 15\/64\"\u003c\/li\u003e\n\u003cli\u003eBase Plate Steel Thickness: 5\/8\"\u003c\/li\u003e\n\u003c\/ul\u003e\n\u003cul\u003e\n\u003cli\u003eCombo (Symmetrical and Asymmetrical) Arm Assembly\u003c\/li\u003e\n\u003cli\u003eStraight Front\/Rear 3 Stage reach from 22 7\/8\" to 42 5\/8\"\u003c\/li\u003e\n\u003cli\u003eStraight Rear 2 Stage reach from 33 5\/8\" to 52 7\/8\"\u003c\/li\u003e\n\u003cli\u003eScrew-in pads 4 pieces included\u003c\/li\u003e\n\u003cli\u003eTruck adapters 4 pieces included\u003c\/li\u003e\n\u003c\/ul\u003e\n\u003cul\u003e\n\u003cli\u003eDouble point safety lock release\u003c\/li\u003e\n\u003cli\u003eAutomatic arm lock restraints\u003c\/li\u003e\n\u003cli\u003eRelief valve built in power pump to prevent overloading\u003c\/li\u003e\n\u003cli\u003eDoor guards protection rubber\u003c\/li\u003e\n\u003cli\u003eUp-limit switch to protect cylinders working stroke used in safe length scope\u003c\/li\u003e\n\u003cli\u003eHeavy duty 3\/8\" diameter cable and 5\" pulley that reduce high stress on synchronization process and increase cable life\u003c\/li\u003e\n\u003cli\u003eUpgraded Floor Plate, Beveled Diamond Plate Steel 5\/32\" with Supporting Bracket.\u003c\/li\u003e\n\u003cli\u003eUltra high molecular self lubricating nylon slider that ensures carriage smooth moving up and down\u003c\/li\u003e\n\u003c\/ul\u003e\n\u003cul\u003e\n\u003cli\u003eLifting operation by pressing \"UP\" button on motor\u003c\/li\u003e\n\u003cli\u003eManual lowering operation by pressing lever\u003c\/li\u003e\n\u003cli\u003eRelief valve built in power pump to prevent overloading\u003c\/li\u003e\n\u003cli\u003eOverall Height: 113 5\/8\"\u003c\/li\u003e\n\u003cli\u003eOverall Width: 134 5\/16\"\u003c\/li\u003e\n\u003cli\u003eMaximum Lift height with Truck Adapters: 81\"\u003c\/li\u003e\n\u003cli\u003eMaximum Lift height without Truck Adapters: 75\"\u003c\/li\u003e\n\u003cli\u003eMinimum Height of Arm Top: 4\"\u003c\/li\u003e\n\u003cli\u003eCarriage to Carriage Width (Drive through clearance): 100\"\u003c\/li\u003e\n\u003cli\u003eColumn to Column Width: 109\"\u003c\/li\u003e\n\u003cli\u003eColumn Cross Section: 11\"L x 7\"W\u003c\/li\u003e\n\u003cli\u003eFloor Plate Cross Section: 10 5\/8\"W x 1 7\/8\"H\u003c\/li\u003e\n\u003cli\u003eDriving Mode: Dual hydraulic cylinders, chain drive\u003c\/li\u003e\n\u003cli\u003eMotor: 220V Single Phase 3HP 10A (recommend a 30A breaker)\u003c\/li\u003e\n\u003cli\u003eHydraulic Oil: 3-5 gallons AW32\/AW46\u003c\/li\u003e\n\u003cli\u003eLifting Capacity: 10,000 LB\u003c\/li\u003e\n\u003cli\u003eTime to full rise: 50 sec\u003c\/li\u003e\n\u003c\/ul\u003e\n\u003cul\u003e\n\u003cli\u003eConcrete Requirement: 6\" thick at 3500 psi reinforced with fiberglass or steel (4\" thick for vehicles 9000LB and below)\u003c\/li\u003e\n\u003cli\u003eAnchor bolts\/mounting hardware included\u003c\/li\u003e\n\u003cli\u003eTool trays and toe guards included\u003c\/li\u003e\n\u003cli\u003eShipping Weight: 1,350 LB\u003c\/li\u003e\n\u003cli\u003eShipping package size: 113\"L x 22\"W x 40\"H\u003c\/li\u003e\n\u003c\/ul\u003e","published_at":"2017-05-01T03:48:39-07:00","created_at":"2017-05-17T15:28:24-07:00","vendor":"APlusLift","type":"Car Lifts","tags":[],"price":184900,"price_min":184900,"price_max":184900,"available":true,"price_varies":false,"compare_at_price":194900,"compare_at_price_min":194900,"compare_at_price_max":194900,"compare_at_price_varies":false,"variants":[{"id":29580430661,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"APlusLift HW-10KBP-A 10,000 LB 2-Post Floor Plate Heavy Duty Car Lift 24 Months Parts Warranty (FREE SHIPPING)","public_title":null,"options":["Default Title"],"price":184900,"weight":612350,"compare_at_price":194900,"inventory_quantity":486,"inventory_management":"shopify","inventory_policy":"deny","barcode":"0760488936375","requires_selling_plan":false,"selling_plan_allocations":[]}],"images":["\/\/cdn.shopify.com\/s\/files\/1\/1751\/1741\/products\/apluslift-hw-10kbp-2-post-floor-plate-car-lift.jpg?v=1604294578","\/\/cdn.shopify.com\/s\/files\/1\/1751\/1741\/products\/apluslift-hw-10kbp-2-post-floor-plate-car-lift-arms.jpg?v=1604294578","\/\/cdn.shopify.com\/s\/files\/1\/1751\/1741\/products\/apluslift-hw-10kbp-2-post-floor-plate-car-lift-carriage-and-arms.jpg?v=1604294578","\/\/cdn.shopify.com\/s\/files\/1\/1751\/1741\/products\/apluslift-hw-10kbp-2-post-floor-plate-car-lift-diagram.png?v=1604294578","\/\/cdn.shopify.com\/s\/files\/1\/1751\/1741\/products\/apluslift-hw-10kbp-2-post-floor-plate-car-lift-carriage.jpg?v=1604294578","\/\/cdn.shopify.com\/s\/files\/1\/1751\/1741\/products\/apluslift-hw-10kbp-2-post-floor-plate-car-lift-locking-details.jpg?v=1604294578","\/\/cdn.shopify.com\/s\/files\/1\/1751\/1741\/products\/apluslift-hw-10kbp-2-post-floor-plate-car-lift-power-unit.jpg?v=1604294578","\/\/cdn.shopify.com\/s\/files\/1\/1751\/1741\/products\/apluslift-hw-10kbp-2-post-floor-plate-car-lift-double-s-column.jpg?v=1604294578","\/\/cdn.shopify.com\/s\/files\/1\/1751\/1741\/products\/apluslift-hw-10kbp-2-post-floor-plate-car-lift-screw-in-pad.jpg?v=1604294578","\/\/cdn.shopify.com\/s\/files\/1\/1751\/1741\/products\/apluslift-hw-10kbp-2-post-floor-plate-car-lift-toe-guards-and-tool-trays.jpg?v=1604294578"],"featured_image":"\/\/cdn.shopify.com\/s\/files\/1\/1751\/1741\/products\/apluslift-hw-10kbp-2-post-floor-plate-car-lift.jpg?v=1604294578","options":["Title"],"media":[{"alt":"APlusLift HW-10KBP-A 10,000 LB 2-Post Floor Plate Heavy Duty Car Lift","id":12069510283422,"position":1,"preview_image":{"aspect_ratio":1.182,"height":3019,"width":3569,"src":"https:\/\/cdn.shopify.com\/s\/files\/1\/1751\/1741\/products\/apluslift-hw-10kbp-2-post-floor-plate-car-lift.jpg?v=1604293848"},"aspect_ratio":1.182,"height":3019,"media_type":"image","src":"https:\/\/cdn.shopify.com\/s\/files\/1\/1751\/1741\/products\/apluslift-hw-10kbp-2-post-floor-plate-car-lift.jpg?v=1604293848","width":3569},{"alt":"APlusLift HW-10KBP-A 10,000 LB 2-Post Floor Plate Heavy Duty Car Lift - Arms","id":12069509955742,"position":2,"preview_image":{"aspect_ratio":1.5,"height":3333,"width":5000,"src":"https:\/\/cdn.shopify.com\/s\/files\/1\/1751\/1741\/products\/apluslift-hw-10kbp-2-post-floor-plate-car-lift-arms.jpg?v=1604293849"},"aspect_ratio":1.5,"height":3333,"media_type":"image","src":"https:\/\/cdn.shopify.com\/s\/files\/1\/1751\/1741\/products\/apluslift-hw-10kbp-2-post-floor-plate-car-lift-arms.jpg?v=1604293849","width":5000},{"alt":"APlusLift HW-10KBP-A 10,000 LB 2-Post Floor Plate Heavy Duty Car Lift - Carriage and Arms","id":12069509988510,"position":3,"preview_image":{"aspect_ratio":1.5,"height":3333,"width":5000,"src":"https:\/\/cdn.shopify.com\/s\/files\/1\/1751\/1741\/products\/apluslift-hw-10kbp-2-post-floor-plate-car-lift-carriage-and-arms.jpg?v=1604293848"},"aspect_ratio":1.5,"height":3333,"media_type":"image","src":"https:\/\/cdn.shopify.com\/s\/files\/1\/1751\/1741\/products\/apluslift-hw-10kbp-2-post-floor-plate-car-lift-carriage-and-arms.jpg?v=1604293848","width":5000},{"alt":"APlusLift HW-10KBP-A 10,000 LB 2-Post Floor Plate Heavy Duty Car Lift - Diagram","id":12069510054046,"position":4,"preview_image":{"aspect_ratio":1.0,"height":2142,"width":2142,"src":"https:\/\/cdn.shopify.com\/s\/files\/1\/1751\/1741\/products\/apluslift-hw-10kbp-2-post-floor-plate-car-lift-diagram.png?v=1604293847"},"aspect_ratio":1.0,"height":2142,"media_type":"image","src":"https:\/\/cdn.shopify.com\/s\/files\/1\/1751\/1741\/products\/apluslift-hw-10kbp-2-post-floor-plate-car-lift-diagram.png?v=1604293847","width":2142},{"alt":"APlusLift HW-10KBP-A 10,000 LB 2-Post Floor Plate Heavy Duty Car Lift - Carriage","id":12069510021278,"position":5,"preview_image":{"aspect_ratio":1.333,"height":1200,"width":1600,"src":"https:\/\/cdn.shopify.com\/s\/files\/1\/1751\/1741\/products\/apluslift-hw-10kbp-2-post-floor-plate-car-lift-carriage.jpg?v=1604293847"},"aspect_ratio":1.333,"height":1200,"media_type":"image","src":"https:\/\/cdn.shopify.com\/s\/files\/1\/1751\/1741\/products\/apluslift-hw-10kbp-2-post-floor-plate-car-lift-carriage.jpg?v=1604293847","width":1600},{"alt":"APlusLift HW-10KBP-A 10,000 LB 2-Post Floor Plate Heavy Duty Car Lift - Locking Details","id":12069510119582,"position":6,"preview_image":{"aspect_ratio":1.333,"height":1200,"width":1600,"src":"https:\/\/cdn.shopify.com\/s\/files\/1\/1751\/1741\/products\/apluslift-hw-10kbp-2-post-floor-plate-car-lift-locking-details.jpg?v=1604293848"},"aspect_ratio":1.333,"height":1200,"media_type":"image","src":"https:\/\/cdn.shopify.com\/s\/files\/1\/1751\/1741\/products\/apluslift-hw-10kbp-2-post-floor-plate-car-lift-locking-details.jpg?v=1604293848","width":1600},{"alt":"APlusLift HW-10KBP-A 10,000 LB 2-Post Floor Plate Heavy Duty Car Lift - Power Unit","id":12069510152350,"position":7,"preview_image":{"aspect_ratio":0.669,"height":1600,"width":1071,"src":"https:\/\/cdn.shopify.com\/s\/files\/1\/1751\/1741\/products\/apluslift-hw-10kbp-2-post-floor-plate-car-lift-power-unit.jpg?v=1604293847"},"aspect_ratio":0.669,"height":1600,"media_type":"image","src":"https:\/\/cdn.shopify.com\/s\/files\/1\/1751\/1741\/products\/apluslift-hw-10kbp-2-post-floor-plate-car-lift-power-unit.jpg?v=1604293847","width":1071},{"alt":"APlusLift HW-10KBP-A 10,000 LB 2-Post Floor Plate Heavy Duty Car Lift - Double S Columns","id":12069510086814,"position":8,"preview_image":{"aspect_ratio":1.333,"height":1200,"width":1600,"src":"https:\/\/cdn.shopify.com\/s\/files\/1\/1751\/1741\/products\/apluslift-hw-10kbp-2-post-floor-plate-car-lift-double-s-column.jpg?v=1604293847"},"aspect_ratio":1.333,"height":1200,"media_type":"image","src":"https:\/\/cdn.shopify.com\/s\/files\/1\/1751\/1741\/products\/apluslift-hw-10kbp-2-post-floor-plate-car-lift-double-s-column.jpg?v=1604293847","width":1600},{"alt":"APlusLift HW-10KBP-A 10,000 LB 2-Post Floor Plate Heavy Duty Car Lift - Screw-In Pad","id":12069510217886,"position":9,"preview_image":{"aspect_ratio":0.667,"height":675,"width":450,"src":"https:\/\/cdn.shopify.com\/s\/files\/1\/1751\/1741\/products\/apluslift-hw-10kbp-2-post-floor-plate-car-lift-screw-in-pad.jpg?v=1604293849"},"aspect_ratio":0.667,"height":675,"media_type":"image","src":"https:\/\/cdn.shopify.com\/s\/files\/1\/1751\/1741\/products\/apluslift-hw-10kbp-2-post-floor-plate-car-lift-screw-in-pad.jpg?v=1604293849","width":450},{"alt":"APlusLift HW-10KBP-A 10,000 LB 2-Post Floor Plate Heavy Duty Car Lift - Toe Guards and Tool Trays","id":12069510250654,"position":10,"preview_image":{"aspect_ratio":1.52,"height":400,"width":608,"src":"https:\/\/cdn.shopify.com\/s\/files\/1\/1751\/1741\/products\/apluslift-hw-10kbp-2-post-floor-plate-car-lift-toe-guards-and-tool-trays.jpg?v=1604293846"},"aspect_ratio":1.52,"height":400,"media_type":"image","src":"https:\/\/cdn.shopify.com\/s\/files\/1\/1751\/1741\/products\/apluslift-hw-10kbp-2-post-floor-plate-car-lift-toe-guards-and-tool-trays.jpg?v=1604293846","width":608}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003cul\u003e\n\u003cli\u003e\n\u003ch3\u003eCombo (Symmetrical and Asymmetrical) Arm Assembly with Screw-in Pads!\u003c\/h3\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003ch3\u003eCE Certified Lift Structure and Hydraulic System\u003c\/h3\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003ch3\u003e6'9\" Lift Height Maximum with Truck Adapters\u003c\/h3\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003ch3\u003eAll Robot Welded Structure with Durable Powder Coated Finish\u003c\/h3\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003ch3\u003eDouble Seal Rings Protecting PU Material\u003c\/h3\u003e\n\u003c\/li\u003e\n\u003cli\u003e\n\u003ch3\u003eCarriage Material Q355 (ASTM A572), Stronger Than Normal Q235 Steel\u003c\/h3\u003e\n\u003c\/li\u003e\n\u003c\/ul\u003e\n\u003ch3\u003eAPlusLift HW-10KBP-A car lift (auto hoist) is one of the most affordable floor plate car lift with 10,000 LB Heavy Duty and Strong Double \"S\" Column Design. Our auto lifts are upgraded to use thicker steel for stronger support (Column Steel upgraded to 13\/64\" from 11\/64\"; Carriage and Arm Steel upgraded to 15\/64\" from 3\/16\"; Carriage yoke upgraded to 9\/16\" from 15\/64\")\u003c\/h3\u003e\n\u003ch3\u003eAPlusLift HW-10KBP-A car lifts are built with quality materials and good workmanship. We do not use recycled materials to save cost for parts such as cylinder seal rings. Suggestions to improve our products and service are always welcome!\u003c\/h3\u003e\n\u003ch3\u003eSelf Pickup Locations with Discount: Los Angeles (CA), Atlanta (GA), Indianapolis (IN), Kansas City (MO), Charlotte (NC), New Holland (PA), Dallas (TX), and Tacoma (WA).\u003c\/h3\u003e\n\u003ch3\u003eFrequently Asked \u003ca href=\"\/pages\/product-order-and-shipping-questions\"\u003eProduct, Order, and Shipping Questions\u003c\/a\u003e and \u003ca href=\"\/pages\/installation-questions#10k\"\u003eInstallation Questions\u003c\/a\u003e\n\u003c\/h3\u003e\n\u003ch3\u003e\u003cspan style=\"color: red;\" color=\"red\"\u003ePlease Note We Are The Only Seller of APlusLift Products on The Website, Amazon, and eBay.\u003c\/span\u003e\u003c\/h3\u003e\n\u003ch2\u003eSpecification and Features\u003c\/h2\u003e\n\u003cul\u003e\n\u003cli\u003e\u003ca href=\"https:\/\/cdn.shopify.com\/s\/files\/1\/1751\/1741\/files\/APlusLift_HW-10KBP.pdf?v=1610167906\"\u003eInstallation Manual\u003c\/a\u003e\u003c\/li\u003e\n\u003c\/ul\u003e\n\u003cul\u003e\n\u003cli\u003eColumn Steel Thickness: 13\/64\"\u003c\/li\u003e\n\u003cli\u003eCarriage Steel Thickness: 15\/64\"\u003c\/li\u003e\n\u003cli\u003eCarriage Yoke Thickness: 9\/16\"\u003c\/li\u003e\n\u003cli\u003eArm Steel Thickness: 15\/64\"\u003c\/li\u003e\n\u003cli\u003eBase Plate Steel Thickness: 5\/8\"\u003c\/li\u003e\n\u003c\/ul\u003e\n\u003cul\u003e\n\u003cli\u003eCombo (Symmetrical and Asymmetrical) Arm Assembly\u003c\/li\u003e\n\u003cli\u003eStraight Front\/Rear 3 Stage reach from 22 7\/8\" to 42 5\/8\"\u003c\/li\u003e\n\u003cli\u003eStraight Rear 2 Stage reach from 33 5\/8\" to 52 7\/8\"\u003c\/li\u003e\n\u003cli\u003eScrew-in pads 4 pieces included\u003c\/li\u003e\n\u003cli\u003eTruck adapters 4 pieces included\u003c\/li\u003e\n\u003c\/ul\u003e\n\u003cul\u003e\n\u003cli\u003eDouble point safety lock release\u003c\/li\u003e\n\u003cli\u003eAutomatic arm lock restraints\u003c\/li\u003e\n\u003cli\u003eRelief valve built in power pump to prevent overloading\u003c\/li\u003e\n\u003cli\u003eDoor guards protection rubber\u003c\/li\u003e\n\u003cli\u003eUp-limit switch to protect cylinders working stroke used in safe length scope\u003c\/li\u003e\n\u003cli\u003eHeavy duty 3\/8\" diameter cable and 5\" pulley that reduce high stress on synchronization process and increase cable life\u003c\/li\u003e\n\u003cli\u003eUpgraded Floor Plate, Beveled Diamond Plate Steel 5\/32\" with Supporting Bracket.\u003c\/li\u003e\n\u003cli\u003eUltra high molecular self lubricating nylon slider that ensures carriage smooth moving up and down\u003c\/li\u003e\n\u003c\/ul\u003e\n\u003cul\u003e\n\u003cli\u003eLifting operation by pressing \"UP\" button on motor\u003c\/li\u003e\n\u003cli\u003eManual lowering operation by pressing lever\u003c\/li\u003e\n\u003cli\u003eRelief valve built in power pump to prevent overloading\u003c\/li\u003e\n\u003cli\u003eOverall Height: 113 5\/8\"\u003c\/li\u003e\n\u003cli\u003eOverall Width: 134 5\/16\"\u003c\/li\u003e\n\u003cli\u003eMaximum Lift height with Truck Adapters: 81\"\u003c\/li\u003e\n\u003cli\u003eMaximum Lift height without Truck Adapters: 75\"\u003c\/li\u003e\n\u003cli\u003eMinimum Height of Arm Top: 4\"\u003c\/li\u003e\n\u003cli\u003eCarriage to Carriage Width (Drive through clearance): 100\"\u003c\/li\u003e\n\u003cli\u003eColumn to Column Width: 109\"\u003c\/li\u003e\n\u003cli\u003eColumn Cross Section: 11\"L x 7\"W\u003c\/li\u003e\n\u003cli\u003eFloor Plate Cross Section: 10 5\/8\"W x 1 7\/8\"H\u003c\/li\u003e\n\u003cli\u003eDriving Mode: Dual hydraulic cylinders, chain drive\u003c\/li\u003e\n\u003cli\u003eMotor: 220V Single Phase 3HP 10A (recommend a 30A breaker)\u003c\/li\u003e\n\u003cli\u003eHydraulic Oil: 3-5 gallons AW32\/AW46\u003c\/li\u003e\n\u003cli\u003eLifting Capacity: 10,000 LB\u003c\/li\u003e\n\u003cli\u003eTime to full rise: 50 sec\u003c\/li\u003e\n\u003c\/ul\u003e\n\u003cul\u003e\n\u003cli\u003eConcrete Requirement: 6\" thick at 3500 psi reinforced with fiberglass or steel (4\" thick for vehicles 9000LB and below)\u003c\/li\u003e\n\u003cli\u003eAnchor bolts\/mounting hardware included\u003c\/li\u003e\n\u003cli\u003eTool trays and toe guards included\u003c\/li\u003e\n\u003cli\u003eShipping Weight: 1,350 LB\u003c\/li\u003e\n\u003cli\u003eShipping package size: 113\"L x 22\"W x 40\"H\u003c\/li\u003e\n\u003c\/ul\u003e"}

APlusLift HW-10KBP-A 10,000 LB 2-Post Floor Plate Heavy Duty Car Lift 24 Months Parts Warranty (FREE SHIPPING)

Product Description
$1,849.00 Free Shipping $1,949.00
Maximum quantity available reached.
  • Combo (Symmetrical and Asymmetrical) Arm Assembly with Screw-in Pads!

  • CE Certified Lift Structure and Hydraulic System

  • 6'9" Lift Height Maximum with Truck Adapters

  • All Robot Welded Structure with Durable Powder Coated Finish

  • Double Seal Rings Protecting PU Material

  • Carriage Material Q355 (ASTM A572), Stronger Than Normal Q235 Steel

APlusLift HW-10KBP-A car lift (auto hoist) is one of the most affordable floor plate car lift with 10,000 LB Heavy Duty and Strong Double "S" Column Design. Our auto lifts are upgraded to use thicker steel for stronger support (Column Steel upgraded to 13/64" from 11/64"; Carriage and Arm Steel upgraded to 15/64" from 3/16"; Carriage yoke upgraded to 9/16" from 15/64")

APlusLift HW-10KBP-A car lifts are built with quality materials and good workmanship. We do not use recycled materials to save cost for parts such as cylinder seal rings. Suggestions to improve our products and service are always welcome!

Self Pickup Locations with Discount: Los Angeles (CA), Atlanta (GA), Indianapolis (IN), Kansas City (MO), Charlotte (NC), New Holland (PA), Dallas (TX), and Tacoma (WA).

Frequently Asked Product, Order, and Shipping Questions and Installation Questions

Please Note We Are The Only Seller of APlusLift Products on The Website, Amazon, and eBay.

Specification and Features

  • Column Steel Thickness: 13/64"
  • Carriage Steel Thickness: 15/64"
  • Carriage Yoke Thickness: 9/16"
  • Arm Steel Thickness: 15/64"
  • Base Plate Steel Thickness: 5/8"
  • Combo (Symmetrical and Asymmetrical) Arm Assembly
  • Straight Front/Rear 3 Stage reach from 22 7/8" to 42 5/8"
  • Straight Rear 2 Stage reach from 33 5/8" to 52 7/8"
  • Screw-in pads 4 pieces included
  • Truck adapters 4 pieces included
  • Double point safety lock release
  • Automatic arm lock restraints
  • Relief valve built in power pump to prevent overloading
  • Door guards protection rubber
  • Up-limit switch to protect cylinders working stroke used in safe length scope
  • Heavy duty 3/8" diameter cable and 5" pulley that reduce high stress on synchronization process and increase cable life
  • Upgraded Floor Plate, Beveled Diamond Plate Steel 5/32" with Supporting Bracket.
  • Ultra high molecular self lubricating nylon slider that ensures carriage smooth moving up and down
  • Lifting operation by pressing "UP" button on motor
  • Manual lowering operation by pressing lever
  • Relief valve built in power pump to prevent overloading
  • Overall Height: 113 5/8"
  • Overall Width: 134 5/16"
  • Maximum Lift height with Truck Adapters: 81"
  • Maximum Lift height without Truck Adapters: 75"
  • Minimum Height of Arm Top: 4"
  • Carriage to Carriage Width (Drive through clearance): 100"
  • Column to Column Width: 109"
  • Column Cross Section: 11"L x 7"W
  • Floor Plate Cross Section: 10 5/8"W x 1 7/8"H
  • Driving Mode: Dual hydraulic cylinders, chain drive
  • Motor: 220V Single Phase 3HP 10A (recommend a 30A breaker)
  • Hydraulic Oil: 3-5 gallons AW32/AW46
  • Lifting Capacity: 10,000 LB
  • Time to full rise: 50 sec
  • Concrete Requirement: 6" thick at 3500 psi reinforced with fiberglass or steel (4" thick for vehicles 9000LB and below)
  • Anchor bolts/mounting hardware included
  • Tool trays and toe guards included
  • Shipping Weight: 1,350 LB
  • Shipping package size: 113"L x 22"W x 40"H

Customer Reviews

Based on 73 reviews Write a review
  • We usually ship in 3 business days after payment. All products are shipped with tracking numbers. We ship to the lower 48 US states, AK, HI, PR, and Canada.
  • We use FedEx, UPS, or USPS for products less than 150LB.
  • We use established LTL freight companies for products over 150LB.
  • For car lifts, we do free shipping to addresses in the lower 48 states, but we cannot provide a liftgate service as they are too long to fit the liftgate. Please prepare your own unloading equipment (like a forklift, bobcat, cherrypicker, or flatbed truck) to unload. If you cannot unload, we can ship to a nearby freight terminal for you to pick up.
  • For motorcycle lifts, we do free shipping to a commercial address (in a business zone) with forklift or a freight terminal in the lower 48 states. Residential address with liftgate service has $60 additional charge.
  • Please text or email us for a nearby freight terminal.
  • Additional freight charges may apply for delayed delivery (cannot accept delivery or pick up from the terminal for over a week), remote areas (e.g. Key West, FL), high cost delivery areas (e.g. Manhattan, NY), non-contiguous states (AK, HI, and PR), and Canada.

Sale, Payment, and Delivery

  • The quality of the products by APlusLift is in accordance with APlusLift's specifications listed on www.apluslift.com and on installation manuals. Final determination of the suitability of the products for the use is the sole responsibility of the buyer.
  • Payment for all products is due before shipment unless other arrangements have been agreed upon in advance.
  • The buyer has the right to inspect the products at the time an place of delivery and notice APlusLift for any shortages and damages within 30 days after such delivery.
  • Delivery will be on paved road only.
  • APlusLift is not liable to any incidental or consequential damages such as lost profits.
  • All order cancellations must be approved by APlusLift and may be subject to restocking fees and other charges.

Warranty Parts

  • Customer satisfaction is most important to us. If you have any problem with the product you received, please contact us ASAP. We will do our best to resolve your problem quickly.
  • We do warranty for parts only. There is no labor warranty on any products.
  • We ship replacement parts for free within the warranty time in lower 48 states. Please let us know if you have any problem with parts.
  • We ship parts with FedEx, UPS, and USPS. Sorry but we do not do overnight shipping.
  • Please to contact us if you want to purchase additional parts.

Return and Refund

  • We accept returns within 30 days after you receive the products.
  • If you want to return a product that is over 500LB, please put the product in the original package or on a pallet and send us a photo for the package. We will send you a return freight label and schedule a pickup by a freight company. After we receive the returned product, we will process the refund.
  • If a product is defected and difficult to repair, we will do 100% refund for the return. For other return reasons, we may charge return freight cost and 10% restocking fee.
  • Our parts are for replacement and upgrade use for APlusLift products only. The original shipping cost, returning shipping cost, and 20% restocking fee may be charged for returns.
  • Once a return product is received and inspected, we will notify you for the approval or rejection of the refund.
  • Usually the refund may take at least two business days to be processed by the bank. If you did not receive the refund after about a week, please reply the email we sent to you or contact us at help@apluslift.com.

Feedback

  • If you are happy with our products, please leave us a positive feedback. We will leave a positive feedback for you in return once we receive your feedback.
  • We never stop improving our products. We appreciate if you have any suggestions for our products.

General Questions:

We apologize. The factory may have forgotten to include the installation manual in the package. You may download the most recent installation manual on the product listing page (see "Installation Manual").

For any damaged/defected/missing parts, please email or text us some photos. We will ship you replacement parts.

Please check the package for damage. When the trucking company picks up the package from the warehouse, the driver checks the package and signs the paperwork. Usually a broken package is caused during the transportation. If the package is damaged, please mark the damage details on the driver's receipt BY YOURSELF (not by the driver). Also please take some photos, which will help us file a claim to the trucking company.

The factory checks each part and tests each product before packing it. Occasionally the product may be missing a part, but it is rare.

If you want to file a claim for a damaged/defected product, please email or text us and our technician will follow up with you. If the damage/defect is caused during the transportation, we will help you prepare a claim to the trucking company or we will file the claim on your behalf. If the defect is caused by the factory, our technician will check with the factory and resolve the issue with you.

HW-9KBP, HW-9KOH, HW-10KBP, and HW-10KOH:

Please set shorter (3-stage) arms to the front and longer (2-stage) arms to the back. To use the arms in asymmetric way, please pull forward a vehicle so that about 1/3 of the vehicle is in front of the column and about 3/2 of the vehicle is behind the column.

For 220V split phase electric power, please connect hot 1 to brown, hot 2 to blue, and ground to yellow/green.

To connect wires to a contactor (if needed), the wiring is Brown-L2, Blue-L3, Green-L2, Red-L3.

Please run the arms up and down several times without a vehicle. The air will bleed from cylinder vent holes automatically.

First, please measure the voltage between two hot lines and see if it is 220-240V. The motor will not start if the voltage is below 220V.

Second, please check to see if the contactor has power input after pushing the push button. If the contactor has no power input, most likely the push button is broken. Please contact us for that.

Third, if the voltage is good, please push the green button (see picture below) on the contactor to enable the power to the motor directly. If the motor can run after pushing the button, most likely the contactor is broken. Please contact us for that.

If the motor still does not start, Please email or text us. Our technician will follow up with you.

First, please run the arms up and down several times. There may be some air in the cylinder. They will bleed out and run as normal.

Second, please adjust the fluid speed valve on the power unit (see the picture below). Please adjust no more than 1/4 of a circle each time. Otherwise the lift may go down too fast.

Third, please check to see if the chains or cables are stuck somewhere.

Fourth, please check to see if the fittings (connecting hoses to power unit or cylinders) are clogged.

If you still have the issue, please email or text us. Our technician will follow up with you.

The lowering speed is about 60 seconds for safety reasons. The speed is controlled by a fluid speed valve on the power unit. Some lifts will go down much faster with a vehicle on it.

If the arms go down too slowly, please adjust the fluid speed value counterclockwise 1/4 of a circle each time. Otherwise the lift may go down too fast.

Usually it is because the connection between the hydraulic hose and the cylinder/power unit is not fastened. There is an O-ring on the hose and an O-ring with the fitting to prevent it from leaking. Please use a wrench to lock the fitting. You may check this photo for reference. If the fitting cannot be tightened, please text or email us.

Please check the picture below for installing tool trays. The door guards are on the top of the carriages (there are two small holes drilled)

The big snap ring locks the bottom of the screw-in pad (pad holder) under the arm to prevent the pad holder from dropping out of the arm hole. If you use truck adapters, please remove the big snap rings.

The HW-10KOH-A lift has only one bracket. The other side is a long bracket. You may check this photo below.

TR-10C and TR-10CX:

Please email or text us with some photos and the nameplate (on one of the posts with the model name and manufacturing date on it). Our technician will follow up with you.

HW-8S, HW-8SXLT, HW-8S-JACK, and HW-8S-AJ:

Please connect hot to brown, neutral to blue, and ground to yellow/green.

Please always remove the vehicle first before you roll the 4-post car lift to another place. It is NOT safe to move the car lift with a vehicle on it.

This lift is the same model as a few other brands. They are manufactured from the same factory. You may check some YouTube videos online.

If you have any further questions, please email or text us with some photos and the nameplate (on one of the posts with the model name and manufacturing date on it). Our technician will follow up with you.

HW-SL6600X:

Please connect hot to brown, neutral to blue, and ground to yellow/green.

The cable connected to the power unit is a testing cable. The factory tested each power unit before packing it. Please discard it and use the other cable to connect the power unit to a power outlet.

HW-12S and HW-14S:

Please email or text us with some photos and the nameplate (on one of the posts with the model name and manufacturing date on it). Our technician will follow up with you.

MT1500, MT1500X, and MT1500XLT:

There are some YouTube videos online of people putting the lift table together. The lift table is mostly assembled. You may flip it over, connect the cylinder hose to the foot pedal, connect to air compressor, install accessories, and test it. Please do NOT to let the scissor frame sit on the cylinder hose.

The foot pedal has a coupler connecting to the cylinder hose. This coupler is specially made for the cylinder hose. It does not fit any air compressor hose. You may find a matched coupler for your air compressor hose at a local hardware store. The foot pedal hole is 1/4" female NPT.

The foot pedal does not go back to the neutral point automatically after pushing up and down. You may test the lift table several times to find the neutral point. If the neutral point is very difficult to find, please email or text us. Our technician will follow up.

The lift table is air operated. It does not use hydraulic fluid. The factory adds some extra lubricant oil in the cylinder to prevent it from getting rusty (especially when the lift table is used for a long time). You may wipe it off and use it as normal

You may slide the front extension above the lift table and choose one of the two fitting positions to make the table 96" or 110" long. It is NOT connected side by side with the lift table.

There are two grease zerks at the both ends of the central shaft already. The two extra grease zerks in the bag are backup in case zerks on the shaft get lost during the transportation.

MT2200 and MT2200X:

The 2200LB motorcycle lift table does not come with a free service jack or portable kit. They are optional. You may email or text us to purchase a new one.

Please email or text us and send us a photo of the worn/damaged/defected part and a photo for the nameplate (with model name and manufacturing date on it). Our technician will follow up with you.
